1. SPECIFICATIONS
1-1. Outdoor Unit
<Digital Inverter>
Model name Outdoor unit
RAV-GM
561AT
*
P
*
801AT
*
P
*
Power supply
1 phase 220-240V, 50Hz
1 phase 220V, 60Hz
(Power exclusive to outdoor is required.)
Compressor
Type Hermetic compressor
Motor (kW) 1.1 1.6
Pole 4 4
Refrigerant charged (kg)
0.9 1.3
Refrigerant control Pulse motor valve
Inter
connecting pipe
Standard length (m) 7.5 7.5
Min. length (m) 5 5
Max. total length (m) 30 30
Additional refrigerant charge
under long piping connector
20g/m
(21m to 30m)
35g/m
(21m to 30m)
Height
difference
Outdoor lower (m) 30 30
Outdoor higher (m) 30 30
Outer dimension
Height (mm) 550 550
Width (mm) 780 780
Depth (mm) 290 290
Appearance Silky shade (Muncel 1Y8.5/0.5)
Total weight (kg) 40
43
Heat exchanger Finned tube
Fan unit
Fan Propeller fan
Standard air flow high (m3/min.) 40 45
Motor (W) 43 43
Connecting pipe
Gas side (mm) 12.7 15.9
Liquid side (mm) 6.4 9.5
Sound pressure level Cooling/Heating (dB·A) 46/48 48/52
Sound power level Cooling/Heating (dB·A) 63/65 65/69
Outside air temperature, Cooling °C (Dry bulb temp.) 46 to -15
Outside air temperature, Heating °C (Wet bulb temp.) 15 to -15
