Strainer
Packed valve
Outer dia. Ø12.7
Packed valve
Outer dia. Ø6.35
TS sensor
P
TD sensor
TL sensor
TŌ sensor
Distributor
4-way valve
(STF-H0108)
Muffler
Ø19.05 × 160L
2-step muffler
Ø19 .05 × 200L
Rotary compressor
(DX150A1T-20F)
TE
sensor
Heat exchanger
Ø7 ripple, 2 rows,
24 steps
FP1.3 flat fin
PMV
(Pulse Motor Valve)
(DPF(S01)1.8C-15)
R32 : 0.9 kg
Cooling
Heating
Pressure
switch
3-2. Outdoor Unit
RAV-GM561AT
P
Pressure Pipe surface temperature (°C)
Compressor
revolutions per
second (rps)
*
Indoor
fan
Indoor/Outdoor
temp. conditions
(DB/WB) (°C)
(MPa) (kg/cm
2
G)
Discharge
(TD)
Suction
(TS)
Indoor heat
exchanger
(TC)
Outdoor heat
exchanger
(TE)
Pd Ps Pd Ps Indoor Outdoor
Cooling
Standard 3.11 0.96 31.7 9.8
90 13 12 43 60
HIGH 27/19 35/-
Overload 3.37 1.08 34.4 11.0 77 21 17 53 35 HIGH 32/24 46/-
Low load 1.90 0.70 19.4 7.1 48 7 5 30 50 LOW 18/15.5 -5/-
Heating
Standard 2.27 0.63 23.1 6.4
82 2 36
1
65
HIGH 20/- 7/6
Overload 2.86 0.89 29.2 9.1 86 17 47 11 95 LOW 28/- 24/18
Low load 1.86 0.25 19.0 2.6 69 -14 31 -15 98 HIGH 15/- -10/(70%)
* 4 poles are provided to this compressor.
The compressor frequency (Hz) measured with a clamp meter is 2 times of revolutions (rps) of the compressor.
