5. SPECIFICATIONS OF ELECTRICAL PARTS
RAV-GM561AT
*
P
*
, GM801AT
*
P
*
No. Parts name Type Specifications
1 Compressor
DX150A1T-20F
3 phase, 4P, 1100 W
2 Fan motor ICF-140-43-4R Output 43 W
3 4-way valve coil STF-H01AZ1724A1 -
4 PMV coil PQ-M01012-000082 -
5 High-pressure SW ACB-4UB83W OFF:4.15MPa
6 Reactor CH-57-Z-T
8.88~10mH, 16A
7 P.C. board MCC-1645 -
8 Fuse (Mounted on P.C. board) - AC250 V, 25 A
9 Fuse - AC250 V, 6.3 A
10 Fuse (Mounted on P.C. board) - AC250 V, 3.15 A
11 Outdoor temp. sensor (TO sensor) - 10 kΩ at 25°C
12 Heat exchanger temp. sensor (TE sensor) - 10 kΩ at 25°C
13 Suction temp. sensor (TS sensor) - 10 kΩ at 25°C
14 Discharge temp. sensor (TD sensor) - 50 kΩ at 25°C
15 Heat exchanger temp. sensor (TL sensor) - 50 kΩ at 25°C
16 Compressor thermo. (Protection) CS-12AL OFF: 125 ± 4°C, ON: 90 ± 5°C
RAV-GM1101AT
*
P
*
,GM1401AT
*
P
*
No. Parts name Type Specifications
1 Compressor
DX330A2T-20M
3 phase, 4P, 3000W
2 Fan motor WDF-340-A100-1 Output 100 W
3 4-way valve coil STF-H01AZ1724A1 -
4 PMV coil CAM-MD12TF-18 -
5 High-pressure SW ACB-4UB83W OFF:4.15MPa
6 Reactor CH-62
5.34~5.99mH, 18.5A
7 P.C. board MCC-1648 -
8 Fuse (Mounted on P.C. board) - AC250 V, 25 A
9 Fuse - AC250 V, 10 A
10 Fuse (Mounted on P.C. board) - AC250 V, 3.15 A
11 Outdoor temp. sensor (TO sensor) - 10 kΩ at 25°C
12 Heat exchanger temp. sensor (TE sensor) - 10 kΩ at 25°C
13 Suction temp. sensor (TS sensor) - 10 kΩ at 25°C
14 Discharge temp. sensor (TD sensor) - 50 kΩ at 25°C
15 Heat exchanger temp. sensor (TL sensor) - 50 kΩ at 25°C
16 Compressor thermo. (Protection) CS-12AL OFF: 125 ± 4°C, ON: 90 ± 5°C
