OIL CONTROL VALVE ASSY
REMOVAL
-
INSTALLATION
Note:
Before disconnecting the control lever link, release the residual pressure in the material han
-
dling system piping by operating the control lever, set the mast in the neutral state and lowering
the fork to the bottom position.
Removal Procedure
1
Remove the toe board.
2
Disconnect the control valve lever link
3
Disconnect the piping.
4
Remove the oil control valve set bolt.
5
Remove the oil control valve
ASSY.
Installation Procedure
The installation procedure is the reverse of the removal procedure.
Note:
Apply grease to the oil control valve lever link parts.
Check the hydraulic oil level, and add if insufficient.
