[Point
31
Removal:
SST 09320
-
23000
-
71
Installation:
SST 09950
-
6001 0
---
O
09950
-
7001 0
---
@
[Point
41
Removal.Installation:
SST 09509
-
55020
Installation:
Adjust the front axle hub starting force.
1. Install the plate.
2. Fully tighten the bearing lock nut, and rotate the hub by
4
to
5
turns to run in the bearing.
3. Return the bearing lock nut by 1/12 to
116
turn (30 to
60°), and rotate the hub by
4
to 5 turns again.
4.
Set a spring scale on a hub bolt, and measure the start
-
ing force.
Standard:
25.5
-
72.6
N
(2.6
-
7.4
kg9
[5.7
-
16.3
Ibf]
5.
If the standard is not satisfied, adjust the degree of bear
-
ing lock nut tightening for adjustment.
6. Install the nut lock bolt.
Coat thread tightener (08833
-
00070) on the nut lock bolt
before tightening.
