Installation Procedure
The installation procedure is the reverse of the removal procedure.
Note:
Apply molybdenum disulfide grease on the mast support bushing and mast support cap interior
surfaces. Apply MP grease to the tilt cylinder front pin.
Adjust lift cylinder uneven movement when the mast ASSY, outer mast, inner mast or either lift
cylinder is replaced. (See page
4
-
34.)
Adjust the chain tension after installation.
Point Operations
[Point
I]
Removal
-
Installation:
SST 09630
-
23600
-
71
[Point
21
Removal:
If
the
fitting
is hard, use the SST for removal.
SST 09950
-
4001 1
[Point
31
Removal:
SST 0981 0
-
201 72
-
71
To Next Page
