ECm3 EC0@4
CHARGING
SYSTEM
-
On-Vehicle
I
(c)
[Referencel
Using
SST,
check
the
drive
belt
tension.
SST
0921
6-00020
and 0921
6-00030
Drive belt
tension:
Single
belt
tyPe
New
belt
45
-
65
kg
Used
belt
25
-
45
kg
Double
belt
type
New belt
30
-
50
kg
Used
belt
20
-
40 kg
lf the belt
tension
is
not
within specification,
adjust
it.
HINT:
When
checking
the
tension,
be sure
the
gauge
is
on
the
belt
protrusion
(single
belt
type)
or
belt
groove
(double
belt type).
4. VISUALLY
CHECK
ALTERNATOR
WIRING
AND
LISTEN
FOR
ABNORMAL
NOISES
(a)
Check
that the
wiring
is
in
good
condition'
(b)
Check
that
there
are
no abnormal
noises
from the
alternator
while
the
engine
is
running'
Single
Belt
TYPe
Double
Belt
TYPe
/\/\
//------^,,\ /r--
---r\
1(-_-2\
/(.-_r\
L---Wr---\7
€--V------\1
/vtn
^r\^rEr\r\
-.\,U\-r\-/\-A.r\-'\,o-^
cHo445
CHO691
5.
INSPECT
CHARGE
WARNING
LIGHT
CIRCUIT
(a)
Warm
up the
engine
and
then
turn
it
off.
(b)
Trun
off all
accessories.
(c)
Turn the
starter
switch
to
"ON."
Check
that
the
charge
warning
light
is lit.
(d)
Start
the
engine.
Check
that
the
light
goes
out.
lf the
light
does
not operate
as specified,
troubleshoot
the
warning
light circuit.
CHECK
CHARGING
CIRCUIT
WITHOUT
LOAD
HINT:
lf a
battery./alternator
tester
is available,
connect
the tester
to the
charging
circuit
as
per
the
manufacturer's
instructions.
Ammeter
Alternator
Voltmeter
6.
