ENGINE MECHANICAL
-
Cylinder Block
EM-89
liameter
nt
(See
er mea-
ace the
rft.
IGS
rg.
t4:
EMl2An
(b)
Align
the oil holes
of the bearing and
cylinder block.
(c)
Using SST,
install
the
camshaft bearings.
ssT o9215-OOO1 2
(O9215-OOO2O,
09215-00440,
0921 5-00470)
and
0921
5-OO1OO
(0921
5-00130, 09215-00140,
0921 s-OO1
50, 0921 5-OO1 60)
D.
Check camshaft
oil clearance
(See
page
EM-88)
E.
lnstallexpansionplug
(a)
Apply
liquid
sealer to the
expansion
plug
surface of
the cylinder
block.
(b)
Using
SST and a hammer,
drive
in
the expansion
plug
to a distance
ol
2
mm
(0.08
in.) from
the
cylinder
block edge.
ssT
09215-0OO1 2
(O9215-0O47O)
INSPECTION
OF
VALVE LIFTERS
AND
VALVE
LIFTER
BORES
INSPECT
VALVE
LIFTER
OIL
CLEARANCE
(a)
Using a cylinder
gauge,
measure
the
valve
lifter
bore
diameter.
Bore
diameter: 27.O1O
-
27.O3O
mm
(1.0634
-
1.O642 in.)
(b)
Using
a
micrometer,
measure
the valve lifter
dia-
meter.
Lifter
diameter: 26.955
-
26.975
mm
(1.0612
-
1.O620 in.)
(c)
Subtract the valve lifter
diameter measurement
from
the valve lifter
bore diameter
measurement.
Standard
oilclearance:
0.035
-
O.O75 mm
(O.OO14
-
O.OO3O
in.)
Maximum
oilclearance:
O.1O mm
(O.OO39
in.)
lf
the oil clearance is
greater
than maximum, replace
the
valve lifters.
EMl267
EM6035 EM1052
