66
2-1. Instrument cluster
The display of the speedometer can be selected from two types, analog or
digital. (P. 75)
Analog speedometer
Tachometer
Displays the engine speed in revolutions per minute
Speedometer
Displays the vehicle speed
Clock (P.69)
Fuel gauge
Displays the quantity of fuel remaining in the tank
Engine coolant temperature gauge
Displays the engine coolant temperature
Odometer, trip meter and instrument cluster light control display
Odometer:
Displays the total distance that the vehicle has been driven
Trip meter:
Displays the distance the vehicle has been driven since the meter was last reset.
Gauges and meters (with 7-inch display)
The meters display various drive information.
Meter display
A
B
D
E
F
