Figure 7-6 Backup Log Page
7.2 Web Server
You can log in web management interface, thereby manage and maintain the device.
Following is the page of Web Server.
Figure 7-7 Web Server Page
HTTPS:
HTTPS (Hypertext Transfer Protocol Secure) is enabled by default.
Secure Server
Port:
Designate a secure server port for web server in HTTPS mode. By default the
port is 443.
Server Port:
Designate a server port for web server in HTTP mode. By default the port is 80.
Session
Timeout:
Set the session timeout time. If you do nothing with the web management
page within the timeout time, the system will log out automatically. Please
login again if you want to go back to web management page.
7.3 Management Access
Management Access Control allows you to configure up to four MAC addresses of the hosts that
are allowed to log in to the web management page of the EAP. Click Add PC’s MAC and the MAC
address of the current host will be added to MAC address list.
48
