TP-Link AX5400 User Manual

114
Chapter 16
Manage the Router
1. Tick the Enable checkbox of Remote Management.
2. Keep the HTTPS and HTTP port as default settings (recommended) or enter a value
between 1024 and 65535.
3. Select Specified Device for Remote Managers.
4. In the Only this IP Address field, enter the IP address of the remote device to manage
the router.
5. Click SAVE.
Devices using this WAN IP can manage the router by logging in to http://Router’s WAN
IP:port number (such as http://113.116.60.229:1024).
Tips: The router’s WAN IP is usually a dynamic IP. Please refer to Set Up a Dynamic DNS Service Account if you want
to log in to the router through a domain name.
16. 7. System Log
When the router does not work normally, you can save the system log and send it to the
technical support for troubleshooting.
• To save the system log locally:
1. Visit http://tplinkwifi.net, and log in your TP-Link ID or the password you set for the
router.
2. Go to Advanced > System > System Log.
3. Choose the type and level of the system logs as needed.

TP-Link AX5400 Specifications

General

Model	Archer AX73
Wi-Fi Standard	Wi-Fi 6 (802.11ax)
Bands	Dual-Band
Maximum Speed	5400 Mbps
2.4 GHz Speed	574 Mbps
5 GHz Speed	4804 Mbps
Frequency	2.4 GHz and 5 GHz
Antenna	6x External Antennas
Processor	1.5 GHz Triple-Core CPU
Ports	1x Gigabit WAN, 4x Gigabit LAN, 1x USB 3.0
Security	WPA3, WPA2
Features	OFDMA, MU-MIMO, Beamforming
Memory	512 MB RAM
