15
Chapter 4
Set Up Internet Connection
OR
2. Launch the Tether app and log in with your TP-Link ID.
Note: If you don’t have a TP-Link ID, create one first.
3. Tap the + button and select Router > Wireless Router. Follow the steps to complete
the setup and connect to the internet.
4. Connect your devices to the newly configured wireless networks of the router and
enjoy the internet!
4. 3. Manually Set Up Your Internet Connection
In this part, you can check your current internet connection settings. You can also
modify the settings according to the service information provided by your ISP.
Follow the steps below to check or modify your internet connection settings.
1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for
the router.
2. Go to Internet.
3. Select your internet connection type from the drop-down list.
4. Follow the instructions on the page to continue the configuration. Parameters on the
figures are just used for demonstration.
1 ) If you choose Dynamic IP, you need to select whether to clone the MAC address.
Dynamic IP users are usually equipped with a cable TV or fiber cable.

Table of Contents

Other manuals for TP-Link AX5400

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TP-Link AX5400 and is the answer not in the manual?

TP-Link AX5400 Specifications

General IconGeneral
ModelArcher AX73
Wi-Fi StandardWi-Fi 6 (802.11ax)
BandsDual-Band
Maximum Speed5400 Mbps
2.4 GHz Speed574 Mbps
5 GHz Speed4804 Mbps
Frequency2.4 GHz and 5 GHz
Antenna6x External Antennas
Processor1.5 GHz Triple-Core CPU
Ports1x Gigabit WAN, 4x Gigabit LAN, 1x USB 3.0
SecurityWPA3, WPA2
FeaturesOFDMA, MU-MIMO, Beamforming
Memory512 MB RAM
