TP-Link Omada EAP230-Wall User Manual

98
Configure Daylight Saving Time
Daylight saving time is the practice of advancing clocks during summer months so that
evening daylight lasts longer, while sacrificing normal sunrise times. The EAP provides
daylight saving time configuration.
Follow the steps below to configure daylight saving time:
1. Check the box to enable Daylight Saving.
2. Select the mode of daylight saving time. Three modes are available: Predefined Mode,
Recurring Mode and Date Mode.
3. Configure the related parameters of the selected mode.
■ Predefined Mode
If you select Predefined Mode, choose your region from the drop-down list and the EAP
will use the predefined daylight saving time of the selected region.
There are four regions provided: USA, European, Austrilia and New Zealand. The
following table introduces the predefined daylight saving time of each region.
USA From 2: 00 a.m. on the Second Sunday in March to 2:00 a.m. on the First
Sunday in November.
European From 1: 00 a.m. on the Last Sunday in March to 1:00 a.m. on the Last
Sunday in October.
Australia From 2:00 a.m. on the First Sunday in October to 3:00 a.m. on the First
Sunday in April.
New Zealand From 2: 00 a.m. on the Last Sunday in September to 3:00 a.m. on the
First Sunday in April.

TP-Link Omada EAP230-Wall Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Frequency band	2.4 - 5 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at
Virtual LAN features	Port-based VLAN, VLAN mapping
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Transmitting power (CE)	20 - 23 dBm
Maximum data transfer rate	1167 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Compatible operating systems	Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10
Number of products included	2 pc(s)
Security algorithms	64-bit WEP, 128-bit WEP, 152-bit WEP, SNMP, SNMPv2, WPA, WPA-PSK, WPA2-Enterprise, WPA2-PSK
Number of SSID supported	16
Service Set Identifier (SSID) features	Multiple SSIDs
Placement	Wall
Product color	White
LED indicators	Operation
Antenna type	Internal
Antenna features	Integrated antenna
Antennas quantity	2
Antenna gain level (max)	3.6 dBi
Power consumption (max)	25.5 W
Power consumption (typical)	9 W
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	1
Harmonized System (HS) code	85176990
Package depth	130 mm
Package width	118 mm
Package height	47 mm
Package weight	210 g
Sustainability certificates	CE, RoHS

Weight and Dimensions

Width	86.8 mm
Height	30.2 mm
