TP-Link Omada EAP230-Wall User Manual

31
Select the frequency band (2.4GHz/5GHz) and configure the following parameters.
Wireless Mode Select the IEEE 802.11 mode the radio uses.
• For 2.4GHz:
802.11b/g/n/ax mixed: All of 802.11b, 802.11g, 802.11n, and 802.11ax
clients operating in the 2.4GHz frequency can connect to the EAP. Note
that 802.11ax is only available for certain devices.
802.11b/g/n mixed: All of 802.11b, 802.11g, and 802.11n clients operating
in the 2.4GHz frequency can connect to the EAP.
802.11b/g mixed: Both 802.11b and 802.11g clients can connect to the
EAP.
802.11n only: Only 802.11n clients can connect to the EAP.
• For 5GHz:
802.11a/n/ac/ax mixed: All of 802.11a, 802.11n, 802.11ac, and 802.11ax
clients operating in the 5GHz frequency can connect to the EAP. Note that
802.11ax is only available for certain devices.
802.11a/n/ac mixed: All of 802.11a, 802.11n, and 802.11ac clients
operating in the 5GHz frequency can connect to the EAP.
802.11n/ac mixed: Both 802.11n clients and 802.11ac clients operating in
the 5GHz frequency can connect to the EAP.
802.11ac only: Only 802.11ac clients can connect to the EAP.
Channel Width Select the channel width of the EAP. The available options differ among
different EAPs.
For some EAPs, available options include 20MHz, 40MHz and Auto.
For some EAPs, available options include 20MHz, 40MHz, 80MHz and Auto.
For other EAPs, available options include 20MHz, 40MHz, 80MHz, 160MHz
and Auto.
When the radio mode includes 802.11n, we recommend you set the channel
bandwidth to 20/40 MHz or 20/40/80MHz to improve the transmission
speed. However, you may choose a lower bandwidth due to the following
reasons:
• To increase the available number of channels within the limited total
bandwidth.
• To avoid interference from overlapping channels occupied by other
devices in the environment.
• Lower bandwidth can concentrate higher transmit power, increasing
stability of wireless links over long distances.

TP-Link Omada EAP230-Wall Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Frequency band	2.4 - 5 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at
Virtual LAN features	Port-based VLAN, VLAN mapping
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Transmitting power (CE)	20 - 23 dBm
Maximum data transfer rate	1167 Mbit/s
Maximum data transfer rate (5 GHz)	867 Mbit/s
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Compatible operating systems	Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10
Number of products included	2 pc(s)
Security algorithms	64-bit WEP, 128-bit WEP, 152-bit WEP, SNMP, SNMPv2, WPA, WPA-PSK, WPA2-Enterprise, WPA2-PSK
Number of SSID supported	16
Service Set Identifier (SSID) features	Multiple SSIDs
Placement	Wall
Product color	White
LED indicators	Operation
Antenna type	Internal
Antenna features	Integrated antenna
Antennas quantity	2
Antenna gain level (max)	3.6 dBi
Power consumption (max)	25.5 W
Power consumption (typical)	9 W
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	1
Harmonized System (HS) code	85176990
Package depth	130 mm
Package width	118 mm
Package height	47 mm
Package weight	210 g
Sustainability certificates	CE, RoHS

Weight and Dimensions

Width	86.8 mm
Height	30.2 mm
