TP-Link Omada EAP245 User Manual

37
2.1.3 Configure the MLO Network (Only for Wi-Fi 7 Devices)
MLO (Multi-Link Operation) enables Wi-Fi 7 devices to simultaneously send and receive
data across different bands and channels. This ensures fast and reliable connections even
in dense network environments.
To configure an MLO network, go to Wireless > Wireless Settings > MLO and click Add.
Configure the parameters and save the settings.
SSID Specify a name for the MLO network.
Band Select the bands to form the MLO network. Available band options may
vary by model.
SSID Broadcast With the option enabled, AP will broadcast the SSID to the nearby hosts,
so that those hosts can find the wireless network identified by this SSID.
If this option is disabled, users must enter the SSID manually to connect
to the AP.
Security Mode/
Version/
Encryption
Configure the security settings of the wireless network.
For detailed instructions, refer to
2.1.1 Configure SSIDs
.
Guest Network With this option enabled, guest network will block clients from reaching
any private IP subnet.

TP-Link Omada EAP245 Specifications

General

5 GHz	Yes
MIMO type	Multi User MIMO
Frequency band	2.4 - 5 GHz
Cabling technology	10/100/1000Base-T(X)
Transmitting power	27 dBmW
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af
Virtual LAN features	SSID-based VLAN assignment
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Transmitting power (CE)	20 - 23 dBm
Transmitting power (FCC)	24 dBm
Maximum data transfer rate	1750 Mbit/s
Maximum data transfer rate (5 GHz)	1300 Mbit/s
Maximum data transfer rate (2.4 GHz)	450 Mbit/s
Placement	Ceiling, Wall
Product color	White
LED indicators	Power
Cable lock slot type	Kensington
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	16
Service Set Identifier (SSID) features	Multiple SSIDs
Compatible operating systems	Microsoft Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Antenna type	Internal
Antenna features	Integrated antenna
Antenna direction type	Omni-directional
Antenna gain level (max)	4 dBi
Output current	1.5 A
Output voltage	12 V
Power consumption (typical)	12.7 W
Power over Ethernet (PoE) type supported	Active PoE, Passive PoE
Cables included	AC
Number of products included	1 pc(s)
Package depth	340 mm
Package width	228 mm
Package height	65 mm
Package weight	1180 g
Harmonized System (HS) code	85176990
Sustainability certificates	CE, Federal Communications Commission (FCC), RoHS

Weight and Dimensions

Width	180 mm
Height	47.5 mm
