TP-Link Omada EAP245 User Manual

5
1.1 Determine the Management Method
Before building your network, choose a proper method to manage your EAPs. You have
the following two options:
■ Controller Mode
If you want to manage a large-scale network centrally, choose Controller Mode. In
Controller Mode, you can configure and monitor mass EAPs, switches, and gateways via
Omada SDN Controller. For detailed instructions, go to the Support Webpage of Omada
Controller and download the User Guide.
■ Standalone Mode
If you want to manage only a few EAPs, choose Standalone Mode. In Standalone Mode,
you can singly configure and monitor your EAPs via Omada APP or a web browser, and
each EAP has its own management page.
This chapter introduces how to start configuring the EAP in Standalone Mode.
Note:
• Standalone Mode is inaccessible while the EAP is managed by a controller. To turn the EAP back
to Standalone Mode, you can forget the EAP on the controller or reset the EAP.
• To make your EAPs discovered by the controller, you need to configure
5.2 Controller Settings
in certain scenarios.

TP-Link Omada EAP245 Specifications

General

5 GHz	Yes
MIMO type	Multi User MIMO
Frequency band	2.4 - 5 GHz
Cabling technology	10/100/1000Base-T(X)
Transmitting power	27 dBmW
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af
Virtual LAN features	SSID-based VLAN assignment
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Transmitting power (CE)	20 - 23 dBm
Transmitting power (FCC)	24 dBm
Maximum data transfer rate	1750 Mbit/s
Maximum data transfer rate (5 GHz)	1300 Mbit/s
Maximum data transfer rate (2.4 GHz)	450 Mbit/s
Placement	Ceiling, Wall
Product color	White
LED indicators	Power
Cable lock slot type	Kensington
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	16
Service Set Identifier (SSID) features	Multiple SSIDs
Compatible operating systems	Microsoft Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Antenna type	Internal
Antenna features	Integrated antenna
Antenna direction type	Omni-directional
Antenna gain level (max)	4 dBi
Output current	1.5 A
Output voltage	12 V
Power consumption (typical)	12.7 W
Power over Ethernet (PoE) type supported	Active PoE, Passive PoE
Cables included	AC
Number of products included	1 pc(s)
Package depth	340 mm
Package width	228 mm
Package height	65 mm
Package weight	1180 g
Harmonized System (HS) code	85176990
Sustainability certificates	CE, Federal Communications Commission (FCC), RoHS

Weight and Dimensions

Width	180 mm
Height	47.5 mm
