TP-Link Omada EAP245 User Manual

45
Follow the steps below to configure External Radius Server as the portal authentication
type:
1. Select the SSID on which the portal will take effect.
2. Build a RADIUS server on the network and make sure that it is reachable by the EAP.
3. Go to the Portal configuration page on the EAP. Select External Radius Server as the
authentication type.
3. Configure the relevant parameters as the following table shows:
RADIUS Server IP Enter the IP address of RADIUS server.
RADIUS Port Enter the port of the RADIUS server.
RADIUS Password Enter the password of the RADIUS server.
NAS ID Configure a Network Access Server Identifier (NAS ID) using 1
to 64 characters on the portal. The NAS ID is sent to the RADIUS
server by the EAP through an authentication request packet. With
the NAS ID which classifies users to different groups, the RADIUS
server can send a customized authentication response.
RADIUS Accounting Enable or disable RADIUS accounting feature.
Accounting Server IP Enter the IP address of the accounting server.
Accounting Server Port Enter the port number of the accounting server.
Accounting Server
Passsword
Enter the shared secret key of the accounting server.
Interim Update With this option enabled, you can specify the duration between
accounting information updates. By default, the function is
disabled.
Enter the appropriate duration between updates for EAPs in
Interim Update Interval.
Interim Interval With Interim Update enabled, specify the appropriate duration
between updates for EAPs. The default duration is 600 seconds.
Authentication Timeout Specify the value of authentication timeout.
A client’s authentication will expire after the authentication
timeout and the client needs to log in to the authentication page
again to access the network.
Options include 1 Hour, 8 Hours, 24 Hours, 7 Days, and Custom.
With Custom selected, you can customize the time in days, hours,
and minutes.

TP-Link Omada EAP245 Specifications

General

5 GHz	Yes
MIMO type	Multi User MIMO
Frequency band	2.4 - 5 GHz
Cabling technology	10/100/1000Base-T(X)
Transmitting power	27 dBmW
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af
Virtual LAN features	SSID-based VLAN assignment
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Transmitting power (CE)	20 - 23 dBm
Transmitting power (FCC)	24 dBm
Maximum data transfer rate	1750 Mbit/s
Maximum data transfer rate (5 GHz)	1300 Mbit/s
Maximum data transfer rate (2.4 GHz)	450 Mbit/s
Placement	Ceiling, Wall
Product color	White
LED indicators	Power
Cable lock slot type	Kensington
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Security algorithms	64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Number of SSID supported	16
Service Set Identifier (SSID) features	Multiple SSIDs
Compatible operating systems	Microsoft Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Antenna type	Internal
Antenna features	Integrated antenna
Antenna direction type	Omni-directional
Antenna gain level (max)	4 dBi
Output current	1.5 A
Output voltage	12 V
Power consumption (typical)	12.7 W
Power over Ethernet (PoE) type supported	Active PoE, Passive PoE
Cables included	AC
Number of products included	1 pc(s)
Package depth	340 mm
Package width	228 mm
Package height	65 mm
Package weight	1180 g
Harmonized System (HS) code	85176990
Sustainability certificates	CE, Federal Communications Commission (FCC), RoHS

Weight and Dimensions

Width	180 mm
Height	47.5 mm
