TP-Link TL-WA854RE User Manual

TL-WA854RE
300Mbps Universal WiFi Range Extender User Guide
13
 Profile Name - The name you give to your wireless networks. By default, it's the same as
root SSID, but you can change it to any other names that you can easily remember and
distinguish.
 Root SSID - The wireless network name of your root AP this profile will connect to.
 MAC of Root Device - The MAC of your root device this profile will connect to.
 Wireless Security - The security type of your root wireless networks this profile will refer
to. Please make sure it's the same as the root AP's.
 Wireless Password - The wireless password of your root AP. Please make sure it's the
same as your root AP.
Click Save to save this profile in the profile list and go back to the Profile List page.
Click Back to go back to the Profile List page, without saving any configuration on this page.
3. After you’ve set and saved the profile, it will return to the profile list page and display as in
Figure 4-4.
Figure 4-4 Add or Modify the Profile
Click Edit to further edit the profile(s), or Delete to delete the profile(s).
Click Connect to connect the range extender to the wireless network that you have chosen in
the profile list.
Click Add to add a new profile to the list.
Click Delete All to delete all the information in the profile list.
4.4 Network
The Network option allows you to customize your local network manually by changing the default
settings of the Range Extender.
Figure 4-5 Network Menu
Selecting Network > LAN will enable you to configure the IP parameters of Network on this page.

TP-Link TL-WA854RE Specifications

General

5 GHz	No
2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	70M: -68dBm@10% PER\\r 130M: -68dBm@10% PER\\r 108M: -68dBm@10% PER\\r 54M: -68dBm@10% PER\\r 11M: -85dBm@8% PER\\r 6M: -88dBm@10% PER\\r 1M: -90dBm@8% PER
Maximum data transfer rate	300 Mbit/s
Certification	CE, RoHS
Product color	White
Antennas quantity	2
Quantity per pack	1 pc(s)
Security algorithms	128-bit WEP, 152-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	3 W
Type	Network repeater
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Compatible operating systems	Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, 8, Mac OS, NetWare, UNIX or Linux.
Transmitting power (CE)	15 dBm
Harmonized System (HS) code	85171800
Wi-Fi band	Single-band (2.4 GHz)
Cabling technology	10/100Base-T(X)
Ethernet LAN (RJ-45) ports	1
Package depth	101.5 mm
Package width	156.5 mm
Package height	89 mm
Package weight	180 g

Weight and Dimensions

Depth	65.8 mm
Width	110 mm
Height	75.2 mm
