TP-Link TL-WA854RE User Manual

TL-WA854RE
300Mbps Universal WiFi Range Extender User Guide
31
Appendix B: Troubleshooting
T1. How do I restore my Range Extender’s configuration to its factory default settings?
There are TWO methods available to restore the factory defaults.
Method 1:
With the Range Extender TL-WA854RE powered on, use a pin to press and hold the RESET
button on the rear panel for more than 8 seconds before releasing it.
Method 2:
Get logged in to the web-based management page of TL-WA854RE, then go to “System
Tools -> Factory Defaults” and click “Restore”.

Note:
Once the Range Extender is reset, the current configuration settings will be lost and you will
need to reconfigure it.
T2. What can I do if I forget my password?
1) Restore the Range Extender’s configuration to its factory default settings. If you don’t
know how to do that, please refer to previous T1;
2) Use the default user name and password: admin, admin;
3) Try to reconfigure your Range Extender by following the instructions of this UG.
T3. What can I do if I cannot access the web-based configuration page?
1) Check to verify all the connections (either wireless or wired ones) are proper. If yes,
please proceed to the next step; otherwise, check the connections again.
2) Try to obtain an IP address and gateway; if succeed, open your web-browser, enter the
default domain http://tplinkextender.net
in the address field and get logged in.
If you are unable to log in, please RESET the device, and then use the default IP address
to get into the web-based configuration page, reconfigure the device.
3) Feel free to contact our technical support, if the problem still persists.

TP-Link TL-WA854RE Specifications

General

5 GHz	No
2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	70M: -68dBm@10% PER\\r 130M: -68dBm@10% PER\\r 108M: -68dBm@10% PER\\r 54M: -68dBm@10% PER\\r 11M: -85dBm@8% PER\\r 6M: -88dBm@10% PER\\r 1M: -90dBm@8% PER
Maximum data transfer rate	300 Mbit/s
Certification	CE, RoHS
Product color	White
Antennas quantity	2
Quantity per pack	1 pc(s)
Security algorithms	128-bit WEP, 152-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	3 W
Type	Network repeater
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Compatible operating systems	Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, 8, Mac OS, NetWare, UNIX or Linux.
Transmitting power (CE)	15 dBm
Harmonized System (HS) code	85171800
Wi-Fi band	Single-band (2.4 GHz)
Cabling technology	10/100Base-T(X)
Ethernet LAN (RJ-45) ports	1
Package depth	101.5 mm
Package width	156.5 mm
Package height	89 mm
Package weight	180 g

Weight and Dimensions

Depth	65.8 mm
Width	110 mm
Height	75.2 mm
