Routine Maintenance
70
UNT-SVX041D-EN
Replacement Parts
When ordering replacement
parts, refer to model and
serial number located on
the unit namepl
ate, which is
located on the fan/motor cover.
Table 30.
Filter size
Filter Size (1 inch thi
ck)
Unit Size
Width (in.)
Height (in.)
300
12.15
18.375
400
12.15
18.375
600
15.15
26.375
800
15.15
26.375
1000
19.15
30.375
1200
19.15
30.375
69
71
