Configuration Properties (nci)
Variable function Variable name SNVT type Profile
TR200
parame-
ter
Max. motor speed [%] nciMaxSpeed SNVT_lev_percent VSD 6010 4-13
Min. motor speed [%] nciMinSpeed SNVT_lev_percent VSD 6010 4-11
Nom. motor speed [RPM] nciNmlSpeed SNVT_rpm VSD 6010 1-25
Nom. motor frequency [Hz] nciNmlFreq SNVT_freq_hz VSD 6010 1-23
Min. ramp-up time [s] nciRampUpTime SNVT_time_sec VSD 6010 3-41
Min. ramp-down time [s] nciRampDownTime SNVT_time_sec VSD 6010 3-42
Heartbeat time [s] nciSndHrtBt SNVT_time_sec VSD 6010 -
A range of network configuration variables (SCPTs) is available for configuration of the adjustable frequency
drive parameters. These parameters require setting only once, usually following installation.
Please note that the settings written to configuration properties (NCIs) will be stored in the non-volatile mem-
ory. Continuous writing to configuration properties may damage the non-volatile memory.
Network Variable Description - VSD Profile - input
Adjustable Frequency Drive Speed Setpoint
Variable name: SNVT type: State: Value: Command:
nviDrvSpeedStpt SNVT_switch 0 (False) Any Stop
1 (True) 0 Running 0%
1 (True) 1-200 Running 0.5% to 100%
1 (True) 201-255 Running 100%
0xFF (default) Any AUTO (invalid, no action)
This input variable provides start / stop control and a speed reference.
Network Variable Description - VSD Profile - Output
Drive Speed
Variable
name:
SNVT
type:
Value:
nvoDrvSpeed SNVT_lev_percent
Min: Max: Resolution:
-163.840% +163.830% 0.005%
This variable contains the adjustable frequency drive speed as a percentage of the nominal speed.
Configuration of the system
5-18 TR200 LonWorks
