Dimensions
SO-SVN048A-EN 17
Pedestal Drawings
Figure 12. Pedestal drawing - D1 drive
11.2
8.5
9.4
12.8
15.7
14.6
5.3
9.8
SHOWN WITHOUT
COVER PLATES
INSTALLED
Figure 13. Pedestal drawing - D2 drive
14.6
16.5
15.7
14.9
12.5
9.4
5.3
9.8
SHOWN WITHOUT
COVER PLATES
INSTALLED
