Pre-Installation
Required Tools
Normal service tools are required to perform the majority of the
work. A service technician with a well stocked tool chest should
have the right tools to perform the job. In addition to the normal
service tools and hardware, the following is a partial list of
specific field supplied hardware/software components and
special tools that are also required to perform the display
retrofit:
• RS-232 male DB9 to female DB9 pin to pin serial cable to
connect the DynaView™ to a PC or laptop computer
Note:
– The cable must NOT be a null-modem cable.
– The cable must be less than 50 feet in length.
• Type A to Type B USB cable to connect the Tracer
®
UC800
controller to a PC or laptop computer
• A PC or laptop computer equipped with the following:
– KestrelView™ service software, version 14.0 or newer
– Tracer TU service software, version 9.0.322 or newer
– RTHD UC800 firmware build 3.03 or later (refer to
“Preparing Tracer® TU on the Service Computer,”
p. 25)
• South pole magnet screwdriver (TOL01343)
• Electronics vacuum
•Drill
• 3/16-inch drill bit
• 3/8-inch drill bit for display arm
• 2.5-inch hole saw (close mount kit only)
• Phillips screwdriver
• Wrench for fastening the bolts for the panel
• Wire cutter for large and small gage wire
• Vacuum pump
• Oil pump
• Impact drill for concrete
Parts
Table 2. Components – close mount 460 volts
Kit Part Number Mnemonic Part Number Description Qty
Close Mount Components
127500010001
RNG02318 X13640734010 Choke Core M-116 5
531405110100 Core Support Bracket 1
531405470100 Buss Bar, Formed (for motor connection) 2
531405480100 Buss Bar, Straight (for motor connection) 1
BRD02944 X13650733060 Dual Relay output Ref 1A8 (latest revision) 1
HLD00579 X13260721020 Relay, 4PDT, 120VAC, 8amps 2
RAL01142 X13260722010 Relay Socket, 4PDT, Din rail mount 2
X13500224070 Din rail 4inch 1
X13491363010 Din Rail End Stop 4
507117910001 Strut Channel, 1.625-inch x 1.625-inch x 5ft (black color) 1
507117920001 Strut Channel Base, 4-inch x 6-inch (black color) 1
507117930001 Strut Channel L Bracket 1
507117960001 .75-inch conduit connector 90 degree 1
507117970001 .75-inch Conduit Connector Straight 1
X19080029040 0.75-inch conduit - AFD/relay signal wires 20 ft
X19010309470 single conductor cable - 16awg UL 1230 blk 125 ft
CAB01534 X19051625030 Global harness Female to Amp connector 78.74-inch 1
CAB01153 X19051624030 Global harness Male to Amp connector 78.74-inch 1
CAB01150 X19051623020 Extension Harness - 78.74-inch 1
X39002507010 Label, Warning (AFD) 1
507117810001 Label, Nameplate 1
SO-SVN048*-EN KIT IOM (supplied by Trane) 1
507117830001 Schematics Printed on mylar 1
BAS-SVX54*-EN Drive IOM 1
507118200001 AFD Label 1
X39003759010 Label, Technical support 1
