SO-SVN048A-EN 9
Dimensions
Unit Submittal Drawings
Figure 2. D1 drive, 2 conduit, 460 and 575V, below 185 amps - standard drive orientation
17.76
50.67
12.80
1.67
14.62
4.60
13.57
5.00
11.88
22.13
10.16
3.19
3.44
