Trane RTHD Installation Instructions

Pre-Installation
SO-SVN048A-EN 19
127500010001 507118300001 Motor Terminal Shield 1
Conduit Kits
127500020001
2 Conduit Kit
X19038200000 Connector, 2-inch conduit 4
X19120032060 2-inch Conduit sleeve 4
507118010001 PWR WIRE ASSEMBLY D1 - B 1
507118030001 PWR WIRE ASSEMBLY D1 - D 1
507118080001 Modified pedestal plate (Dwg provided) 1
507117990001 AFD Drive Pedestal D1H 1
127500030001
4 Conduit Kit
(small base)
X19038200000 Connector, 2-inch conduit 8
X19120032060 2-inch Conduit sleeve 8
507118000001 PWR WIRE ASSEMBLY D1 - A 1
507118010001 PWR WIRE ASSEMBLY D1 - B 1
507118020001 PWR WIRE ASSEMBLY D1 - C 1
507118030001 PWR WIRE ASSEMBLY D1 - D 1
507118110001 Modified pedestal plate (Dwg provided) 1
507117990001 AFD Drive Pedestal D1H 1
127500040001
4 Conduit Kit
(large base)
X19038200000 Connector, 2-inch conduit 8
X19120032060 2-inch Conduit sleeve 8
507118040001 PWR WIRE ASSEMBLY D2 - A 1
507118050001 PWR WIRE ASSEMBLY D2 - B 1
507118060001 PWR WIRE ASSEMBLY D2 - C 1
507118070001 PWR WIRE ASSEMBLY D2 - D 1
507118110001 Modified pedestal plate (Dwg provided) 1
507118180001 AFD Drive Pedestal D2H 1
VFD DRIVE (one only)
127500110001 X13171807001
AFD DRIVE, 460V, IP21, 110KW,134X2754,
TR-200N110T4E21H2TGC7XXSXXXXAXBXCXXXXDX
127500120001 X13171807002
AFD DRIVE, 460V, IP21, 132KW, 134X2755,
TR-200N132T4E21H2TGC7XXSXXXXAXBXCXXXXDX
127500130001 X13171807003
AFD DRIVE, 460V, IP21, 160KW, 134X2756,
TR-200N160T4E21H2TGC7XXSXXXXAXBXCXXXXDX
127500140001 X13171807004
AFD DRIVE, 460V, IP21, 200KW, 134X2757,
TR-200N200T4E21H2TGC7XXSXXXXAXBXCXXXXDX
127500150001 X13171807005
AFD DRIVE, 460V, IP21, 250KW, 134X2758,
TR-200N250T4E21H2TGC7XXSXXXXAXBXCXXXXDX
127500160001 X13171807006
AFD DRIVE, 460V, IP21, 315KW, 134X2759,
TR-200N315T4E21H2TGC7XXSXXXXAXBXCXXXXDX
CONTROLS (one only)
NONE - UC800 Only for customers with existing UC800 controls
18800260100 UC800/TD7 upgrade Kit with arm
18800270100 UC800/TD7 upgrade Kit without arm
Table 2. Components – close mount 460 volts (continued)
Kit Part Number Mnemonic Part Number Description Qty
