Trane RTHD Installation Instructions

Pre-Installation
22 SO-SVN048A-EN
127500190001 X13171808003
AFD DRIVE, 600V, IP21, 160KW, 134X2762,
TR-200N160T7E21H2TGC7XXSXXXXAXBXCXXXXDX
127500200001 X13171808004
AFD DRIVE, 600V, IP21, 200KW, 134X2763,
TR-200N200T7E21H2TGC7XXSXXXXAXBXCXXXXDX
127500210001 X13171808005
AFD DRIVE, 600V, IP21, 250KW, 134X2764,
TR-200N250T7E21H2TGC7XXSXXXXAXBXCXXXXDX
127500220001 X13171808006
AFD DRIVE, 600V, IP21, 315KW, 134X2765,
TR-200N315T7E21H2TGC7XXSXXXXAXBXCXXXXDX
127500230001 X13171818007
AFD DRIVE, 600V, IP21, 400KW, 134X2766,
TR-200N315T7E21H2TGC7XXSXXXXAXBXCXXXXDX
CONTROLS (one only)
NONE - UC800 Only for customers with existing UC800 controls
18800260100 UC800/TD7 upgrade Kit with arm
18800270100 UC800/TD7 upgrade Kit without arm
Table 4. Components – close mount 575 volts (continued)
Kit Part Number Mnemonic Part Number Description QTY
Table 5. Components – remote mount 575 volts
Kit Part
Number Mnemonic Part Number Description QTY Package Label
Serviceable
Component
Remote Mount Components
127500090001
RNG02318 X13640734010 Choke Core 5
531405110100 Core Support Bracket 1
531405470100 Buss Bar, Formed (for motor connection) 2
531405480100 Buss Bar, Straight (for motor connection) 1
BRD02944 X13650733060 Dual Relay output Ref 1A8 (latest revision) 1
HLD00579 X19220085030 HOUSING; 4 CKT TERM (Phoenix connector) for 1A8 2
RAL01142 X13260721020 Relay, 4PDT, 120VAC, 8amps 2 1K14, 1K15 Relays
X13260722010 Relay Socket, 4PDT, Din rail mount 2
X13500224207 Din rail 4inch 2
X13491363010 Din Rail End Stop 4
SO-SVN048*-EN KIT IOM (supplied by Trane) 1
507117830001 Schematics Printed on mylar 1
BAS-SVX54*-EN Drive IOM 1
507118200001 AFD Label 1
507118300001 Motor Terminal Shield 1
VFD DRIVE (one only)
127500170001 X13171808001
AFD DRIVE, 600V, IP21, 110KW, 134X2760, TR-
200N110T7E21H2TGC7XXSXXXXAXBXCXXXXDX
Y
127500180001 X13171808002
AFD DRIVE, 600V, IP21, 132KW, 134X2761, TR-
200N132T7E21H2TGC7XXSXXXXAXBXCXXXXDX
Y
127500190001 X13171808003
AFD DRIVE, 600V, IP21, 160KW, 134X2762, TR-
200N160T7E21H2TGC7XXSXXXXAXBXCXXXXDX
Y
127500200001 X13171808004
AFD DRIVE, 600V, IP21, 200KW, 134X2763, TR-
200N200T7E21H2TGC7XXSXXXXAXBXCXXXXDX
Y
127500210001 X13171808005
AFD DRIVE, 600V, IP21, 250KW, 134X2764, TR-
200N250T7E21H2TGC7XXSXXXXAXBXCXXXXDX
Y
127500220001 X13171808006
AFD DRIVE, 600V, IP21, 315KW, 134X2765, TR-
200N315T7E21H2TGC7XXSXXXXAXBXCXXXXDX
Y
127500230001 X13171818007
AFD DRIVE, 600V, IP21, 400KW, 134X2766, TR-
200N315T7E21H2TGC7XXSXXXXAXBXCXXXXDX
Y

Trane RTHD Specifications

General

Type	Water-Cooled Chiller
Refrigerant	R-134a
Compressor Type	Helical Rotary (Screw)
Voltage Options	200, 230, 380, 460, 575
Capacity Range	200 - 4000 tons (703 kW - 14, 060 kW)
