Installation
SO-SVN048A-EN 59
Table 17. Non-compressor specific parameters
ID Description Values
0-03 Region Settings [1] North American
0-20 Display Line 1.1 Small [1612] Motor Voltage
0-24 Display Line 3 Large [1617] Speed [RPM]
0-40 [Hand on] Key on LCP [0] Disabled
0-41 [Off] Key on LCP [0] Disabled
0-60 Main Menu Password 999
0-61 Access to Main Menu w/o Password [1] LCP: Read Only
1-03 Torque Characteristics [0] Compressor Torque
1-71 Start Delay 2s
1-73 Flying Start [0] Disabled
1-78 Compressor Start Max Speed [Hz] 20Hz
1-79 Compressor Start Max Time to Trip 10s
1-87 Trip Speed Low [Hz] 25Hz
3-02 Min Reference 30Hz
3-13 Reference Site [1] Remote
3-15 Reference 1 Source [0] No Function
3-41 Ramp 1 Ramp Up Time 10s
3-42 Ramp 1 Ramp Down Time 10s
4-10 Motor Speed Direction [0] Clockwise
4-12 Motor Speed Low Limit [Hz] 30Hz
4-18 Current Limit 107%
8-01 Control Site [2] Controlword only
8-03 Control Timeout Time 15s
8-04 Control Timeout Function [2] Stop
8-30 Protocol [2] Modbus
®
RTU
8-31 Address 3
8-82 Baud Rate [7] 115200 Baud
14-00 Switching Pattern [1] SFAVM
14-03 Overmodulation [0] Off
14-10 Mains Failure [4] Kinetic Back-up
14-12 Function at Mains Imbalance [3] Derate
14-21 Automatic Restart Time 8s
14-50 RFI Filter [0] Off
14-51 DC Link Compensation [1] On
14-60 Function at Over Temperature [1] Derate
14-61 Function at Inverter Overload [1] Derate
14-62 Inv. Overload Derate Current 75%
