Trane Tracer UC600 Installation Guide

BAS-SVP042A-EN
29
Table 7. Binary Values (continued)
Object
Identifi-
er
Object Name
Units of
Measure
Minimum
Maximum
When the Object
Exists
Description
Read/
Write
BV371
Warning: Compressor
2 High Discharge
Press Warning
None None
Units with at least 2
Compressor
Open = Normal
Closed = Warning Active
Read Only
BV375
Warning: Compressor
3 Frostat Warning
None None
Units with at least 3
Compressor
Open = Normal
Closed = Warning Active
Read Only
BV376
Warning: Compressor
3 High Discharge
Press Warning
None None
Units with at least 3
Compressor
Open = Normal
Closed = Warning Active
Read Only
BV380
Warning: Compressor
4 Frostat Warning
None None
Units with at least 4
Compressor
Open = Normal
Closed = Warning Active
Read Only
BV381
Warning: Compressor
4 High Discharge
Press Warning
None None
Units with at least 4
Compressor
Open = Normal
Closed = Warning Active
Read Only
Table 8. Multi-state Values
Object
Identifi-
er
Object Name
Units of
Measure
Minimum
Maximum
When the Object
Exists
Description
Read/
Write
MV1
Occupancy Request
None None All Units
[1, Occupied]
[2, Unoccupied]
[3, Occupied Bypass]
[4, Occupied Standby]
[5, Auto]
Writeable
MV2
Occupancy Status
None None All Units
[1, Occupied]
[2, Unoccupied]
[3, Occupied Bypass]
[4, Occupied Standby]
[5, Auto]
Read Only
MV3
Heat Cool Mode
Request
None None All Units
[1, Auto]
[2, Heat]
[3, Morning Warm-up]
[4, Cool]
[5, Night Purge]
[6, Pre Cool]
[7, Off]
[8, Test]
[9, Emergency Heat]
[10, Fan Only]
[11, Free Cool]
[12, Ice-Making]
[13, Maximum Heat]
[14, Economizer]
[15, Dehumidify]
[16, Calibrate]
Writeable
MV4 Heat Cool Mode Status None None All Units
[1, Auto]
[2, Heat]
[3, Morning Warm-up]
[4, Cool]
[5, Night Purge]
[6, Pre Cool]
[7, Off]
[8, Test]
[9, Emergency Heat]
[10, Fan Only]
[11, Free Cool]
[12, Ice-Making]
[13, Maximum Heat]
[14, Economizer]
[15, Dehumidify]
[16, Calibrate]
Read Only
MV8
Emergency Override
BAS
None None All Units
[1, Normal]
[2, Pressurize]
[3, Depressurize]
[4, Purge]
[5, Shutdown]
[6, Fire]
Writeable
MV39
MJC MSC Factory
Program Version
None None All Units Version 1.4
Read Only
OObbjjeecctt aanndd DDiiaaggnnoossttiicc DDaattaa PPooiinnttss
