Trane Tracer UC600 Installation Guide

48
BAS-SVP042A-EN
Alarming
The UC600 unit for modular self contained units has several objects used for communicating
alarms to the system.
Table 10. Alarm Objects
Object Identifier Object Name Description
Notification Class
BI9
Emergency Stop
Normally Closed Input
Open = Emergency Stop
Closed = Normal
1
BI10
External Auto Stop
Input Status
Normally Closed Input
Open = External Stop
Closed = Auto
1
BI80
Supply Fan 1 VFD
Fault
Normally Closed Input
Open = Alarm
Closed = Auto
1
BI81
Supply Fan 2 VFD
Fault
Normally Closed Input
Open = Alarm
Closed = Auto
1
BI82
Supply Fan 3 VFD
Fault
Normally Closed Input
Open = Alarm
Closed = Auto
1
BI83
Supply Fan 4 VFD
Fault
Normally Closed Input
Open = Alarm
Closed = Auto
1
BI84
Supply Fan 5 VFD
Fault
Normally Closed Input
Open = Alarm
Closed = Auto
1
BI85
Supply Fan 6 VFD
Fault
Normally Closed Input
Open = Alarm
Closed = Auto
1
BI90
Compressor 1 High
Pressure Cutout
Normally Closed Input
Open = Alarm
Closed = Auto
1
BI91
Compressor 2 High
Pressure Cutout
Normally Closed Input
Open = Alarm
Closed = Auto
1
BI92
Compressor 3 High
Pressure Cutout
Normally Closed Input
Open = Alarm
Closed = Auto
1
BI93
Compressor 4 High
Pressure Cutout
Normally Closed Input
Open = Alarm
Closed = Auto
1
BI98
Compressor 1 VFD
Fault
Normally Closed Input
Open = Alarm
Closed = Auto
1
BV15
Diagnostic: Duct
Static Pressure Failure
Open = Normal
Closed = Failure
Non latching Diagnostic, clears
automatically
1
BV19
Diagnostic: Discharge
Air Low Temperature
Lockout
Open = Normal
Closed = Failure
Latching Diagnostic. Cleared with
Alarm Reset or Power Cycle.
1
BV42
Diagnostic: Discharge
Air Temperature
Source Failure
Open = Normal
Closed = Failure
Non latching Diagnostic, clears
automatically
1
BV72
Diagnostic: Dirty Air
Filter
Open = Normal
Closed = Failure
Latching Diagnostic. Cleared with
Filter Alarm Reset or Power Cycle.
2
BV76
Active CoolCoil Control
Sensor Failed
Open = Normal
Closed = Failure
Non latching Diagnostic, clears
automatically
1
BV260
Diagnostic:
Compressor 1
Discharge Pressure
Sensor Failure
Open = Normal
Closed = Failure
Latching Diagnostic. Cleared with
Comp 1 Failure Reset or Power Cycle.
1
BV261
Diagnostic:
Compressor 1 Frostat
Open = Normal
Closed = Failure
Latching Diagnostic. Cleared with
Comp 1 Failure Reset or Power Cycle.
1
