Triumph BONNEVILLE SE User Manual

63
Maintenance and Adjustment
Operation Description Odometer Reading in Miles (Kms) or Time Period,
whichever comes first
First Service A Service B ServiceC ServiceD service
Every 500
(800)
1 month
6,000
(10,000)
1 year
12 , 0 00
(20,000)
2 years
18,000
(30,000)
3 years
24,000
(40,000)
4 years
Engine and oil cooler - check for leaks Day
•••••
Engine oil - replace -
•••••
Engine oil filter - replace -
•••••
Valve clearances - check/adjust -
••
Air cleaner - replace -
••
Spark plugs - check -
••
Spark plugs - replace -
••
Autoscan - Carry out a full Autoscan using the
Triumph diagnostic tool
-
•••••
Fuel filter - replace -
••
Fuel system - check for leaks, chafing etc. Day
•••••
Throttle cables - check/adjust Day
•••••
Lights, instruments and electrical systems - check Day
•••••
Steering - check for free operation Day
•••••
Steering head bearings - check/adjust -
••••
Steering head bearings - lubricate -
••
Forks - check for leaks/smooth operation Day
•••••
Fork oil - replace -
•
Brake fluid levels - check Day
•••••
Brake fluid - replace Every 2 years

Triumph BONNEVILLE SE Specifications

General

Displacement	865cc
Bore x Stroke	90 x 68 mm
Compression Ratio	9.2:1
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	5-speed
Frame	Tubular steel cradle
Engine Type	Air-cooled, DOHC, parallel-twin
Max Torque	68 Nm @ 5800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Exhaust	2-into-2 exhaust system
Front Suspension	41mm forks
Rear Suspension	Twin shocks
Front Brakes	Single 310 mm disc, 2-piston caliper
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.0in
Rear Wheel	17-inch
Rear Tire	130/80 R17
Wheelbase	1490 mm
Fuel Tank Capacity	16 liters
