Triumph BONNEVILLE SE User Manual

Maintenance and Adjustment
64
* Evaporative system fitted to models for certain markets only.
Brake pads - check wear levels Day
•••••
Brake master cylinders - check for fluid leaks -
•••••
Brake calipers, check for fluid leaks and seized pistons -
•••••
Drive chain - lubricate Every 200 miles (300 kms)
Drive chain - wear check Every 500 miles (800 kms)
Drive chain slack - check/adjust Day
•••••
Drive chain rubbing strip - check
••••
Fasteners - inspect visually for security Day
•••••
Wheels - inspect for damage Day
•••••
Spokes (where fitted) - check wheels for broken or
damaged spokes/check spoke tightness
Day
•••••
Wheel bearings - check for wear/smooth operation -
•••••
Tire wear/tire damage - check Day
•••••
Tire pressures - check/adjust Day
•••••
Clutch cable - check/adjust Day
•••••
Stand - check operation Day
•••••
Secondary air injection system - check/clean -
••
Fuel and evaporative* hoses - replace -
•
Operation Description Odometer Reading in Miles (Kms) or Time Period,
whichever comes first
First Service A Service B ServiceC ServiceD service
Every 500
(800)
1 month
6,000
(10,000)
1 year
12 , 0 00
(20,000)
2 years
18,000
(30,000)
3 years
24,000
(40,000)
4 years

Triumph BONNEVILLE SE Specifications

General

Displacement	865cc
Bore x Stroke	90 x 68 mm
Compression Ratio	9.2:1
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	5-speed
Frame	Tubular steel cradle
Engine Type	Air-cooled, DOHC, parallel-twin
Max Torque	68 Nm @ 5800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Exhaust	2-into-2 exhaust system
Front Suspension	41mm forks
Rear Suspension	Twin shocks
Front Brakes	Single 310 mm disc, 2-piston caliper
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.0in
Rear Wheel	17-inch
Rear Tire	130/80 R17
Wheelbase	1490 mm
Fuel Tank Capacity	16 liters
