Triumph Rocket 3 R User Manual

Cleaning and Storage
171
Caution
Products such as window cleaning
fluids, insect remover, rain repellent,
scouring compounds, gasoline or
strong solvents such as alcohol,
acetone, carbon tetrachloride, etc. will
damage the windshield.
Never allow these products to contact
the windshield.
Clean the windshield with a solution of
mild soap or detergent and clean, cold
water.
After cleaning, rinse well and then dry
with a soft, lint-free cloth.
If the transparency of the windshield is
reduced by scratches or oxidation which
cannot be removed, the windshield must
be replaced.
Preparation for Storage
To prepare the motorcycle for storage,
do the following:
•
Clean and dry the entire vehicle
thoroughly.
•
Fill the fuel tank with the correct
grade of unleaded fuel and add a
fuel stabilizer (if available), following
the fuel stabilizer manufacturer's
instructions.
Warning
Gasoline is extremely flammable
and can be explosive under certain
conditions.
Turn the ignition switch off. Do not
smoke.
Make sure the area is well ventilated
and free from any source of flame or
sparks; this includes any appliance
with a pilot light.
•
Remove the spark plug from each
cylinder and put several drops 0.17 fl
oz (5 ml) of engine oil into each
cylinder. Cover the spark plug holes
with a piece of cloth or rag. With
the engine stop switch in the RUN
position, push the starter button for
a few seconds to coat the cylinder
walls with oil. Install the spark plugs,
tightening to 9 lbf ft (12 Nm).
• Change the engine oil and filter (see
page 125).
•
Check and if necessary correct the
tire pressures.

Triumph Rocket 3 R Specifications

General

Displacement	2458 cc
Bore x Stroke	110.2 mm x 85.9 mm
Compression Ratio	10.8:1
Max Torque	221 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Shaft
Gearbox	6-speed
Swingarm	Single-sided, cast aluminium
Front Tyre	150/80 R17 V
Rear Tyre	240/50 R16 V
Seat Height	773 mm
Dry Weight	291 kg
Wheelbase	1677 mm
Engine Type	Liquid-cooled, DOHC, inline 3-cylinder
Max Power	165 hp (123 kW) @ 6000 rpm
Exhaust	Stainless steel 3 into 1 headers with 3 exit silencer
Clutch	Hydraulic, torque assist
Frame	Full aluminium frame
Front Suspension	Showa 47 mm upside-down
Rear Suspension	Showa monoshock with piggyback reservoir, adjustable
Front Brakes	Brembo Stylema® 4-piston radial monobloc calipers
Rear Brakes	Brembo 4-piston monobloc caliper
Front Wheel	17 x 3.5 in
Rear Wheel	16 x 7.5 in
Fuel Tank Capacity	18 L
Instrument Display	TFT multi-functional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, ambient temperature, clock and rider modes
