Triumph Rocket 3 R User Manual

Instruments
26
Note
The low oil pressure warning light will
illuminate if the ignition is switched ON
without running the engine.
Immobilizer/Alarm Indicator Light
This Triumph motorcycle is equipped
with an engine immobilizer which is
activated when the ignition switch is
turned to the OFF position.
Without Alarm Equipped
When the ignition switch is turned to
the OFF position, the immobilizer light
will flash on and off for 24 hours to
show that the engine immobilizer is on.
When the ignition switch is turned to
the ON position the immobilizer and the
indicator light will be off.
If the indicator light remains on it
indicates that the immobilizer has a
malfunction that requires investigation.
Contact an authorized Triumph dealer
as soon as possible to have the fault
checked and rectified.
With Alarm Equipped
The immobilizer/alarm light will
only illuminate when the conditions
described in the genuine Triumph
accessory alarm instructions are met.
Anti-lock Braking System (ABS)
Warning Light
When the ignition switch is
turned to the ON position, it is
normal that the ABS warning
light will flash on and off. The
light will continue to flash after engine
start-up until the motorcycle first
reaches a speed exceeding 6 mph
(10 km/h) when it will go off.
Note
Traction control will not function if
there is a malfunction with the ABS.
The warning lights for the ABS, traction
control and the MIL will be illuminated.
The warning light will not illuminate
again until the engine is restarted
unless there is a fault.
If there is a fault with the ABS system
the warning light will be illuminated and
the general warning symbol will flash.
Warning
If the ABS is not functioning, the brake
system will continue to function as a
non-ABS braking system.
Do not continue to ride for longer than
is necessary with the indicator light
illuminated.
Contact an authorized Triumph dealer
as soon as possible to have the fault
checked and rectified. In this situation
braking too hard will cause the wheels
to lock resulting in loss of motorcycle
control and an accident.
Traction Control (TC) Indicator Light
The Traction Control (TC)
indicator light is used to
indicate that the traction
control system is active and is
working to limit rear wheel slip during
periods of hard acceleration or under
wet or slippery road conditions.

Triumph Rocket 3 R Specifications

General

Displacement	2458 cc
Bore x Stroke	110.2 mm x 85.9 mm
Compression Ratio	10.8:1
Max Torque	221 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Shaft
Gearbox	6-speed
Swingarm	Single-sided, cast aluminium
Front Tyre	150/80 R17 V
Rear Tyre	240/50 R16 V
Seat Height	773 mm
Dry Weight	291 kg
Wheelbase	1677 mm
Engine Type	Liquid-cooled, DOHC, inline 3-cylinder
Max Power	165 hp (123 kW) @ 6000 rpm
Exhaust	Stainless steel 3 into 1 headers with 3 exit silencer
Clutch	Hydraulic, torque assist
Frame	Full aluminium frame
Front Suspension	Showa 47 mm upside-down
Rear Suspension	Showa monoshock with piggyback reservoir, adjustable
Front Brakes	Brembo Stylema® 4-piston radial monobloc calipers
Rear Brakes	Brembo 4-piston monobloc caliper
Front Wheel	17 x 3.5 in
Rear Wheel	16 x 7.5 in
Fuel Tank Capacity	18 L
Instrument Display	TFT multi-functional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, ambient temperature, clock and rider modes
