Triumph Rocket 3 R User Manual

General Information
64
Standard Key Operation
To turn the motorcycle on with the
standard key (or the smart key if the
battery is discharged):
•
Hold the standard key on the
system sensor located on the left
hand side of the motorcycle.
1
1. System sensor location
• The standard key must be held
against the system sensor while
pressing the Engine Start/Stop
switch in either the QUICK START
or Power ON/OFF position (see
page 65).
Master Ignition Switch (if equipped)
The master ignition switch is only
mounted to motorcycles in the United
States and Canada. The master ignition
switch is located on the left hand side of
the motorcycle.
Master Ignition Switch
To operate the motorcycle with the
keyless ignition, the master ignition
switch must be in the ON position.
If the master ignition switch is in the
OFF position then the keyless ignition
cannot be used and the motorcycle can
not be started.

Triumph Rocket 3 R Specifications

General

Displacement	2458 cc
Bore x Stroke	110.2 mm x 85.9 mm
Compression Ratio	10.8:1
Max Torque	221 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Shaft
Gearbox	6-speed
Swingarm	Single-sided, cast aluminium
Front Tyre	150/80 R17 V
Rear Tyre	240/50 R16 V
Seat Height	773 mm
Dry Weight	291 kg
Wheelbase	1677 mm
Engine Type	Liquid-cooled, DOHC, inline 3-cylinder
Max Power	165 hp (123 kW) @ 6000 rpm
Exhaust	Stainless steel 3 into 1 headers with 3 exit silencer
Clutch	Hydraulic, torque assist
Frame	Full aluminium frame
Front Suspension	Showa 47 mm upside-down
Rear Suspension	Showa monoshock with piggyback reservoir, adjustable
Front Brakes	Brembo Stylema® 4-piston radial monobloc calipers
Rear Brakes	Brembo 4-piston monobloc caliper
Front Wheel	17 x 3.5 in
Rear Wheel	16 x 7.5 in
Fuel Tank Capacity	18 L
Instrument Display	TFT multi-functional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, ambient temperature, clock and rider modes
