Triumph Thruxton User Manual

General Information
65
Passenger Seat Installation
To install the passenger seat:
Make sure that the rider’s seat is
correctly fitted.
Align the front locating lugs on the
passenger seat to their locating slots on
the luggage rack subframe.
Gently push the seat forward until the
rear locating lug fits into its hole on the
luggage rack subframe.
cjyo
3
4
2
1
5
1. Luggage rack subframe
2. Front locating lugs
3. Front locating lug slots
4. Rear locating lug
5. Rear locating lug hole
Secure the seat with its fixing and
tighten to 3 Nm.
cjyn
2
1
1. Passenger seat
2. Fixing
Grasp the seat and make sure that it is
securely retained.

Triumph Thruxton Specifications

General

Displacement	1200 cc
Transmission	6-speed
Bore x Stroke	97.6 mm x 80 mm
Max Torque	112 Nm @ 4, 950 rpm
Fuel System	Fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate
Frame	Tubular steel
Rear Suspension	Twin shocks
Front Brakes	Dual 310mm discs, 2-piston calipers
Rear Brakes	Single 220mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17-inch
Length	2100 mm (82.7 in)
Width (Handlebars)	745 mm (29.3 in)
Height	1, 030mm
Seat Height	810mm
Wheelbase	1, 415mm
Rake	22.8 º
Fuel Capacity	14.5 liters
Weight (Dry)	203kg
Weight (Wet)	223kg
Exhaust	2-into-2
