Maintenance
150
Rear Suspension Setting Chart –
Tiger 900 GT (LRH)
Loading
Spring
Preload
1
Rebound
Damping
2
Solo Riding
Normal MIN 1.5
Comfort
(Softer)
MIN 2.5
Sport
(Firmer)
MIN 1
Off-Road
(Broken
Terrain)
MIN 1.25
Off-Road
(Smooth
Terrain)
MIN 0.5
Rider and Luggage 17 1
Rider and Passenger 21 1
Rider, Passenger and
Luggage (not exceeding
limits)
MAX 0.5
1
Number of adjuster turns clockwise from the
fully counterclockwise position.
2
Number of adjuster turns counterclockwise
from the fully clockwise (closed) position.
Rear Suspension Setting Chart –
Tiger 900 Rally and Tiger 900 Rally Pro
Loading
Spring
Preload
1
Rebound
Damping
2
Solo Riding
Normal 10.5 1.25
Comfort
(Softer)
10.5 2
Sport
(Firmer)
10.5 0.75
Off-Road
(Broken
Terrain)
MIN 1
Off-Road
(Smooth
Terrain)
MIN 0.5
Rider and Luggage MAX 1
Rider and Passenger MAX 0.75
Rider, Passenger and
Luggage (not exceeding
limits)
MAX 0.5
1
Number of adjuster turns clockwise from the
fully counterclockwise position.
2
Number of adjuster turns counterclockwise
from the fully clockwise (closed) position.
