General Information
88
To adjust the rider's seat:
• Remove the rider's seat (see
page 86).
• Reposition both seat height
adjusters to the higher or lower
position as required.
• Make sure that both adjuster rails
are fully engaged in their brackets
on the seat.
• Reinstall the rider's seat making
sure the seat tongue is under the
upper bar on the fuel tank for the
high seat position, or under the
lower bar on the fuel tank for the
low seat position, (see page 86).
Heated Seats (if equipped)
The heated seats switches (if equipped)
are located on the left hand side of the
motorcycle.
1
2
1. Rider’s heated seat switch location
2. Passenger’s heated seat switch location
The heated seats will only heat when
the engine is running. When the heated
seats are switched on, the heated seats
symbol will appear in the display. The
selected heat level for each seat will
also be indicated by the color of the
symbol.
There are two levels of heat: low and
high.
1 2
1. Low heat symbol (amber)
2. High heat symbol (red)
N
0 0
2 2
4 4
6 6
8 8
10 10
12 12
0
FE
21.5 10:55
AM
C
o
x1000rpm
ABS
MPH
1 2
1. Rider’s heated seat (low heat selected)
2. Passenger’s heated seat (high heat
selected)
Rider Heated Seat
• For maximum benefit in cold
conditions, from the OFF position
press the rider heated seat switch
once for the high heat setting
initially, and then reduce the heat
level by pressing the rider heated
seat switch again for the low heat
setting when the seat has warmed
up.
• To turn the rider heated seat off,
press and release the rider heated
seat switch until the heated seats
symbol is no longer shown in the
display.
