General Information
39
Display Styles
There are four different display styles to
select from.
Style 03 is used for visual recognition
and consistency throughout this
owner's handbook.
3
0 0
2 2
4 4
6 6
8 8
10 10
12 12
52
STYLE 01
47
47
47
47
STYLE 03
FE
21.5 10:55
AM
C
o
x1000rpm
SET 100
9
ABS
+
MPH
STYLE SELECT
SELECT
STYLE 02 STYLE 04
To select a style, see page 68 for more
information.
Warning Lights
Caution
If a red warning light is shown then
the motorcycle must be stopped
immediately. Read any warning
messages and rectify the issue.
If an amber warning light is shown
then the motorcycle does not need
to be stopped immediately. Read any
warning messages and rectify the
issue.
When the ignition is switched on, the
instrument warning lights will illuminate
for 1.5 seconds and will then go off
(except those which remain on until
the engine starts, as described in the
following pages).
For additional warning and information
messages, see page 44.
Engine Management System
Malfunction Indicator Light (MIL)
The Malfunction Indicator
Light (MIL) for the engine
management system
illuminates when the ignition
is switched ON (to indicate that it is
working) but should not become
illuminated when the engine is running.
If the engine is running and there is
a fault with the engine management
system the MIL will be illuminated and
the general warning symbol will flash.
In such circumstances, the engine
management system may switch to
'limp-home' mode so that the journey
may be completed, if the fault is not so
severe that the engine will not run.
Warning
Reduce speed and do not continue to
ride for longer than is necessary with
the MIL illuminated. The fault may
adversely affect engine performance,
exhaust emissions and fuel
consumption.
Reduced engine performance could
cause a dangerous riding condition,
leading to loss of control and an
accident.
Contact an authorized Triumph dealer
as soon as possible to have the fault
checked and rectified.
