TSC MH261T Series User Manual

- 14 -
2.2.2 Interior View
1
Ribbon rewind spindle
10
Media damper
2
Z axis mechanism adjustment knob
11
Print head
3
Print head pressure adjustment knobs
12
Gap sensor (shown as  )
4
Print head release lever
13
Platen roller
5
Ribbon release button
14
Black mark sensor (shown as )
6
Label roll guard
15
Ribbon sensor
7
Label supply spindle
16
Front label guide
8
Rear label guide
17
Media guide bar
9
Ribbon supply spindle
18
Ribbon guide bar
2
3
4
7
5
6
8
9
10
11
13
12
14
15
17
1
16
18
