- 24 -

3.4 Loading the Media

1. Lift the handle to open the printer

right side cover.

2. Push the print head release lever to

open the print head mechanism.

3. Remove the label roll guard from the

label spindle.

Table of Contents

Questions and Answers:

E
Evan PriceAug 22, 2025
Why is my TSC MH261T Barcode Reader not printing?
- M
  Marcia HicksAug 22, 2025
  Your TSC Barcode Reader might not be printing because the interface cable isn't properly connected, or the wireless or Bluetooth device isn't well connected. Also, the port specified in the Windows driver might be incorrect. Re-connect the cable or try a new one. Reset the wireless device setting. Select the correct printer port in the driver. Ensure the printhead’s harness connector is well connected with the printhead by turning off the printer and plugging the connector again. Check your program for a PRINT command at the end of the file and ensure each command line ends with CRLF.
A
Anna RuizAug 25, 2025
Why is my TSC MH261T printing with poor quality?
- O
  ocarpenterAug 25, 2025
  Poor print quality on your TSC Barcode Reader can occur due to several reasons. The ribbon and media might be loaded incorrectly, there could be dust or adhesive on the print head, the print density or speed might not be set properly, the printhead element could be damaged, the ribbon and media might be incompatible, or the printhead pressure might not be set properly. Reload the supply, clean the print head and platen roller, adjust the print density and print speed. Run a printer self-test to check the print head test pattern for missing dots. Change to proper ribbon or label media. Adjust the printhead pressure adjustment knob and ensure the print carriage is closed properly.
D
Daryl HubbardAug 25, 2025
What to do if my TSC MH261T has a paper jam?
- L
  Lori JonesAug 26, 2025
  If your TSC Barcode Reader has a paper jam, it could be due to the gap/black mark sensor not being set properly, incorrect label size settings, or labels stuck inside the printer mechanism. Calibrate the media sensor, set the correct media size, and remove any stuck labels from inside the printer.
A
Ariana RossAug 27, 2025
How to fix no print on the label with my TSC MH261T?
- C
  Crystal GonzalezAug 27, 2025
  If your TSC Barcode Reader is not printing on the label, it may be because the label or ribbon is loaded incorrectly, you're using the wrong type of paper or ribbon, or the print density setting is incorrect. Follow the media and ribbon loading instructions. Verify that the ribbon and media are compatible and that the ribbon-inked side is correct. Reload the ribbon, clean the printhead, and set the correct density with the media.
K
kkingAug 27, 2025
What to do if my TSC MH261T skips labels when printing?
- K
  Kristi JacksonAug 27, 2025
  If your TSC Barcode Reader skips labels during printing, the label size might not be specified properly, the sensor sensitivity might not be set correctly, or the media sensor could be covered with dust. Check if the label size is set up correctly. Calibrate the sensor using Auto Gap or Manual Gap options. Clear the GAP/Black mark sensor with a blower.
Q
qcampbellAug 28, 2025
Why does my TSC Barcode Reader say 'No Paper'?
- D
  David JohnstonAug 28, 2025
  The TSC Barcode Reader might display 'No Paper' because the label roll has run out, the label is installed incorrectly, or the gap/black mark sensor is not calibrated. Supply a new label roll and refer to the user’s manual for instructions on reinstalling the label roll. Calibrate the gap/black mark sensor.
R
Renee RamirezAug 29, 2025
Why does my TSC MH261T say 'No Ribbon'?
- J
  James ChavezAug 30, 2025
  The TSC Barcode Reader might display 'No Ribbon' because the ribbon roll has run out or the ribbon is installed incorrectly. Supply a new ribbon roll and refer to the user’s manual for instructions on reinstalling the ribbon.
W
William GallagherAug 31, 2025
What causes wrinkle problem with TSC MH261T Barcode Reader?
- K
  kellyarnoldAug 31, 2025
  Wrinkling during printing with your TSC Barcode Reader can be caused by incorrect printhead pressure, improper ribbon or media installation, incorrect print density, or incorrect media feeding. Please refer to section 4.2. Set the suitable density for good print quality. Make sure the label guide touches the edge of the media guide.
K
Kirk PachecoSep 1, 2025
How to fix irregular printing on TSC MH261T?
- A
  allison51Sep 1, 2025
  Irregular printing on your TSC Barcode Reader can occur if the printer is in Hex Dump mode or if the RS-232 setting is incorrect. Turn the printer off and on to skip the dump mode. Re-set the Rs-232 setting.
T
territhomasSep 2, 2025
Why is my TSC MH261T Barcode Reader LCD panel dark and keys not working?
- J
  John SchwartzSep 2, 2025
  If the LCD panel on your TSC Barcode Reader is dark and the keys are not working, the cable between the main PCB and LCD panel might be loose. Check if the cable between the main PCB and LCD is secured.
