1
TTP-246M/344M Bar Code Printer
Service Manual
1. FOUNDAMENTALS ABOUT THE SYSTEM
1.1Printer Overview
1.1.1 Front View
Fig. 1.1 Printer Front View
1.1.2 Rear View
Fig. 1.2 Printer Rear View
Aux. LED
LCD Display
Printer Right
Side Cover
External Label
Feed Opening
RS-232C Port
Power Switch
Power Supply
Connector
Keys
