TTP-246M/344M Bar Code Printer
Service Manual
4.7 Replacing Label Supply Spindle
1. Refer to section 4.2 to remove the Main PCB.
2. Remove the 4 screws from the label roll fixing plate.
3. Remove the 3 screws these are used to connect the label supply spindle onto the main
frame.
screws
screws
screws
