TSI Instruments Aerotrak 9303 Service Manual

5-1
CHAPTER 5
Service Kits for
Replacement
Components
Each contamination control instrument has a few field-replaceable units.
Each service kit below is assembled to replace the main component
(example pump) and associated components (connecting tubes, foam,
and pump power input).
N O T I C E
The following components can only be ordered by the Part Number
S7XXXXXX. The description contains the kit contents with quantities.
TSI
®
will not sell individual kit contents.
Some kits like the O-ring kit will contain a large number (50 or 100
pieces) of O-rings. It is not possible to order individual O-rings. You can
buy common parts like O-rings from a local source provided the
specifications match.
Part Number
Description
S7000001
9303 Pump Assembly
(1) Pump with Connector
(1) Foam Block
(1”) Tubing
S7000002
9303 Filter/Tubing Kit
(10) Filter
(60”) Tygon
®
Tubing (one 6” & one 1.3” for each system)
(10) Tie Wrap
S7000003
9303 Display
(1) Display
S7000005
9303 Detector PCB and For 7301, 7501, 7510 and 7301-P
Remote Models
(1) Detector PCB
S7000006
9303 Key Pad
(5) Key Pad

TSI Instruments Aerotrak 9303 Specifications

General

Size Range .	0.3 to 25 µm
Channel Sizes .	0.3 µm and 5.0 µm fixed; 0.5, 1.0, 2.0, or 2.5 µm selectable middle channel.
Counting Efficiency .	50% at 0.3 µm; 100% for particles > 0.45 µm (per ISO 21501-4 and JIS)
Concentration Limits .	2, 000, 000 particles/ft3 at 5% coincidence loss
Zero Count Level .	<1 count / 5 minutes (per ISO 21501-4 and JIS B9921)
Flow Rate .	0.1 CFM (2.83 L/min)
Calibration .	NIST traceable with TSI® calibration system
Sampling Modes .	Manual and automatic
Sampling Time .	1 second to 99 minutes 59 seconds
Sampling Frequency .	1 to 999 cycles or continuous
Light Source .	Long life laser diode
Sample Probe/Tubing .	Isokinetic sampling probe
Exhaust .	Internal HEPA filter
Vacuum Source .	Internal pump
External Surface .	High impact injection molded plastic
Communication Mode .	USB serial output
Data Storage .	1, 500 sample records
Status Indicators .	Low battery and service
Display .	3.2-in. (8.1 cm) 160 x 160 monochrome LCD
AC Power . (power to AC adapter)	110 to 240 VAC 50-60 Hz Universal in-line power supply with country specific plugs
DC Power . (power to instrument)	9 VDC @ 1.5 A
Battery .	Rechargeable Li-Ion
Battery Life .	Up to 4.5 hours of continuous use
Recharge Time .	< 3 hours

Weight and Dimensions

Dimensions (L x W x H)	9.1 x 6.3 x 2.4 in. (23 x 11 x 6.2 cm) (without isokinetic inlet)
Weight .	1.3 lbs (0.58 kg) with battery
