TurboChef NGC (Tornado) User Manual

35
37
36
43
42
39
40
41
38
25
THE MICROWAVE SYSTEM
 : W
ave Guide Cover/Wave Guide Removal and Replacement
5. Clean the oven floor where the new Wave
Guide Cover will sit with Acetone.
6.
A
pply a
1/8” diameter bead of high temperatur
e
RTV (P/N 102562) along the outside edge of
the flanges surrounding the Wave Guide.
: It is important to use the correct high
temperature
RTV as supplied by TurboChef.
7. Place the new Wave Guide Cover in place.
Secure with the fourteen
(14) #8 Sheet Metal
Screws remo
v
ed in Step
3.
WAVE GUIDE/WAVE GUIDE COVER PARTS
Figure 17
35. NGC-1097 Assy, Wave Guide Cover
36.
102921
Scr
e
ws,
#8-32 x 3/8”, SS
37. 101688 Screws, #8 x 1/2” Sheet Metal
PTH
38. NGC-1047 Support, Frame
39. 102809 Screws, #8-32 x 3/8” CSK (100
º
)
40. NGC-1106
Assy, Wave Guide #2
41.
100861
M
agnetr
on
#2
42. 100861
Magnetron #1
43.
NGC-1044
Assy
,
W
av
e Guide
#1
