SERVICE PARTS AND ILLUSTRATIONS
-HOT-
CAUTION
shock, connect to prope
rly grounded outlets on
ly.
electrique branchez seulement a une prise
Pour assurer protection c
ontinue contre le choc
correctement mise a terre.
AVERTISSEMENT:
To provide continued prot
ection against elec
trical
DHHS Federal Performance Standard 21 CFR 1030.1
0.
This Oven complies with applicable sections of
received, including in
terference that ma
y cause
2. This device must acc
ept any interferen
ce
1. This device may not cause harmful interference.
Operation is subject to t
he following condition
s:
This device complies with Part 18 of the FCC
Rules.
undesired operation.
WARNING:
NOTICE:
192
193
194
195
196
197
198
198
199
200
201
202
203
197
205
204
206
207
208
3X
4X
4X
4X
2X
3X
2X
Covers and Miscellaneous Parts
192. NGC-1147 Assy, Rear Chassis/Door
193.
NGC-1069-1
Co
v
er
, Left S
ide, NGC Ov
en
194. NGC-1069-2 Cover, Right Side, NGC Oven
195. NGC-1068 Cover, Top, NGC Oven
196.
102748
Scr
e
w, #8-32 x .38 Lg
TORX HD Security
197. 101688 Screw, #8 Serrated Phillips
TRHD, CRES
198. 102921 Screw, #8-32 x 3/8”, PPHD,
SEM, Int Tooth, SS
199. NGC-1071
Co
v
er
, Bottom F
r
ont
200. 100781 Leg. 4”
201. 10191 Hole Plug, 1/2” Dia, Black
202. NGC-1054-1 Assy, Keypad/Display HSNG
203. NGC-1064 Rack, NGC Oven
204.
NGC-1176
Label, Schematic
205. NGC-1177 Label, Service Assistance
206.
NGC-1148
Label, Caution H
ot
207.
102962
Nut, KEPS HEX, #8-32, Ext
Tooth, CRES
208. NGC-1187 Pad, Abrasive Non-slip
FIGURE 37: CO
VERS AND MISCELLANEOUS PARTS
