Tyco Galaxy SC Controller User Manual

Tyco Electronics Galaxy SC Controller J85501F-1
3 - 14 Installation Issue 13 February 2001
30.75
.80
.85
.90
.95
1
1
1
1
1
1
1
1
1
1
0
0
1
1
1
1
1
0
0
0
1
1
0
0
0
1
1
0
0
0
0
1
0
0
1
1
0
0
1
1
31.00
.05
.10
.15
1
1
1
1
1
1
1
1
1
1
1
1
0
0
0
0
0
0
1
1
1
1
0
0
0
1
0
0
1
0
0
1
*Default setting = 26.80 1 = closed 0 = open
Table 3-C: BJA High Voltage Shutdown Setting +/-24V
Voltage
SW201 Bottom SW200 Top
#1 #2 #3 #4 #1 #2 #3 #4
Table 3-D: Switch Positions for Galaxy Controller Basic
and Intelligent Boards
Circuit Pack Switch Pos Default Description Closed Is (1) Open Is (0)
BJB
Basic
processor
SW202-8 1
Front panel
configuration
Enabled Disabled
SW202-7 1
Auto rectifier
restarts
Enabled Disabled
SW202-6 1
Operate major relays
with critical relays
Enabled Disabled
SW202-5 1 Alarm test Enabled Disabled
SW202-4 0
HV shutdown during
alarm test
Enabled Disabled
SW202-3 0 Boost mode Enabled Disabled
SW202-2 0 External timed boost Enabled Disabled
SW202-1 0
Password reset for
independent
controller modem
option
Enabled Disabled
