TYM T194 User Manual

OPERATION
3 - 11
3
3
10. MAINTENANCE(2)
FILLING DIAGRAM AND SERVICE INTERVALS
Filling diagram shows the maintenances required and the intervals. Follow this checking schedule according to each
indices to the satisfactory operation of the machine.
►
No. Check Point New
After
rst
10hrs
Every
50hrs
Every
150hrs
Every
year
Every
of work
Every
end of
work
Reference
page
1 Gear box oil leakage check
○ ○ ○ ○ ○ ○ ○
2 Gear box oil check
○ ○ ○ ○ ○
3 Gear box oil change
◎ ○
4 Gear box oil seal change
○
At Breakage
5 whether blades are tightened up or not
○ ○ ○ ○ ○ ○ ○
6 Blade wear check
○ ○ ○ ○ ○
7 Blade balance and appearance check
○ ○ ○ ○ ○ ○ ○
8 All hardware check
○ ○ ○ ○ ○
9 whether all pins are in place or not
○ ○ ○ ○ ○ ○
10
Greasing check

Pulley holder
○ ○ ○ ○ ○ ○

Belt tension pulley
○ ○ ○ ○ ○ ○

Belt tension arm
○ ○ ○ ○ ○ ○

Rear link shafts
○ ○ ○ ○ ○ ○

Universal Joint
○ ○ ○ ○ ○ ○
