SARA-G3 and SARA-U2 series - System Integration Manual
UBX-13000995 - R26 Appendix
Page 203 of 217
A.4.7 GPIO pins
The same compatible external circuit can be implemented for SARA-G340 / SARA-G350 and LISA series: four
1.8 V GPIOs are provided by SARA-G340 / SARA-G350 modules, providing the same functionalities as LISA series
modules except Module Status and Operating Mode Indications. The SIM_DET pin provides the SIM detection
function on SARA modules rather than the GPIO5 pin as on LISA-U2 series modules.
SARA-G300 and SARA-G310 modules do not provide GPIOs.
A.4.8 Reserved pins
SARA modules RSVD pin 33 must be connected to ground, as does the RSVD pin 5 on LISA modules.
A.4.9 Pin-out comparison between LISA and SARA-G3
Table 68 summarizes the pin electrical differences between LISA and SARA-G3 cellular modules.
Pin Name
N°
SARA-G3 series
N°
LISA-C2 series
LISA-U1 series
LISA-U2 series
Power
VCC
51-53
Normal op. range:
3.35 V – 4.5 V
Extended op. range:
3.00 V – 4.5 V
High pulse current
due to GSM TDMA
61-63
Normal op. range:
3.3 V – 4.4 V
Extended op. range:
Not applicable
No high pulse current
due to CDMA
Normal op. range:
3.4 V – 4.2 V
Extended op. range:
3.1 V – 4.2 V
High pulse current
due to GSM TDMA
Normal op. range:
3.3 V – 4.4 V
Extended op. range:
3.1 V – 4.5 V
High pulse current
due to GSM TDMA
V_BCKP
2
Output characteristics:
2.3 V typ, 2 mA max
Input op. range:
1.0 V – 2.4 V
2
Not Available
Output characteristics:
2.3 V typ, 3 mA max
Input op. range:
1.0 V – 2.5 V
Output characteristics:
1.8 V typ, 3 mA max
Input op. range:
1.0 V – 1.9 V
V_INT
4
Output characteristics:
1.8 V typ, 50 mA max
4
Output characteristics:
1.8 V typ, 50 mA max
Output characteristics:
1.8 V typ, 50 mA max
Output characteristics:
1.8 V typ, 50 mA max
Antenna
ANT
56
RF input/output for Tx/Rx
antenna
68
RF input/output for
Tx/Rx antenna
RF input/output for
Tx/Rx antenna
RF input/output for
main Tx/Rx antenna
ANT_DIV
Not Available
74
Not Available
Not Available
LISA-U230 only:
RF input for
Rx diversity antenna
ANT_DET
62
SARA-G340/SARA-G350:
Input for antenna
detection circuit
Not Available
Internal antenna
detection circuit
Internal antenna
detection circuit
System
PWR_ON
15
No internal pull-up
L-level: -0.10 V – 0.65 V
H-level: 2.00 V – 4.50 V
ON L-level time:
5 ms min
OFF L-level pulse time:
Not Available
19
180 k internal pull-up
L-level: -0.30 V – 0.30 V
H-level: 2.00 V – 4.70 V
ON L-level pulse time:
150 ms min
OFF L-level pulse time:
Not Available
No internal pull-up
L-level: -0.30 V –0.65 V
H-level: 2.00 V – 4.50 V
ON L-level pulse time:
5 ms min
OFF L-level pulse time:
Not Available
No internal pull-up
L-level: -0.30 V – 0.65 V
H-level: 1.50 V – 4.40 V
ON L-level pulse time:
50 µs min / 80 µs max
OFF L-level pulse time:
1 s min
RESET_N
18
Internal diode & pull-up
L-level: -0.30 V – 0.30 V
H-level: 2.00 V – 4.70 V
Reset L-level pulse time:
SARA-G340/SARA-G350:
50 ms min
SARA-G300/SARA-G310:
3 s min
22
550  internal pull-up
L-level: -0.30 V – 0.63 V
H-level: 1.32 V – 2.10 V
Reset L-level pulse time:
300 ms min
10 k internal pull-up
L-level: -0.30 V – 0.65 V
H-level: 1.69 V – 2.48 V
Reset L-level pulse time:
50 ms min
10 k internal pull-up
L-level: -0.30 V – 0.51 V
H-level: 1.32 V – 2.01 V
Reset L-level pulse time:
50 ms min
