Model UT805: OPERATING MANUAL
Note
When making frequency measurement, it must comply
with the following scope (a) requirement:
When 10Hz ~ 1Mz : 150mV a 30V rms.
When > 1Mz~ 10MHz : 300mV a 30V rms
When > 10Mz~ 50MHz : 600mV a 30V rms
When > 50Mz : Unspecified
In the manual range mode, press to up range or
down range to the desired range. button cannot
be used
When frequency measurement has been completed,
disconnect the connection between the testing leads
and the circuit under test, and remove the testing
leads away from the input terminals of the Meter.
