Unitech MS842P User Manual

6
1. Insert another dongle into a
USB port of the computer or
laptop PC.
2. Scan the MAC address on
the label by using the
MS842P scanner.
3. Switch the MS842P off and
power on again.
4. When being successfully connected to the dongle, the scanner will beep
shortly one time with a high tone.
Connecting a USB Interface, Cradle Mode
Cradle Mode (without SCM support)
In order to establish a proper connection between your computer and a scanner
through a cradle into which a dongle is inserted, we suggest that you follow these
step-by-step instructions:
1. Turn on your computer or laptop PC.
2. Plug the adapter cable into the power socket on the cradle.

Unitech MS842P Specifications

General

Type	Handheld bar code reader
Sensor type	CMOS
Scanner type	1D/2D
Tilt reading angle	-60 - 60 °
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 25 (IR 2 of 5), Code 39, Code 93, EAN-13, GS1-128 (UCC/EAN-128), JAN, MSI, Telepen, Trioptic, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39
USB version	2.0
Wireless range	10 m
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Certification	CE, FCC, BSMI, VCCI
Product color	Black, Grey, Yellow
Housing material	-
International Protection (IP) code	IP54
Battery life	10 h
Charging time	4 h
Input voltage	5 V
Battery capacity	1620 mAh
Power consumption	400 mA
Power source type	DC
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	74 mm
Width	89 mm
Height	176 mm
Weight	200 g
Base dimensions	73 x 95 x 200 mm
